RAM Connection 2026 v26.00.00.272 Win x64
RAM Connection 2026 (26.00.00.272) | 456.4 mb
Languages Supported: English, Español, 中文
TheStructural Products development teamis pleased to announce the availability ofRAM Connection 2026 (26.00.00.272)is steel connection analysis and design software for virtually any connection type.
RAM Connection 2026 (26.00.00.272) Release Notes - Updated June 2026
1. Bentley Copilot Integration.Bentley Copilot integration provides AI-assisted access to documentation and workflow guidance directly within the application.
Users can search and navigate:
- RAM Connection documentation
- Help topics
- Workflow guidance
- Product information
Users can access this information through conversational AI directly within RAM Connection.
Close
Figure 1. Bentley Copilot interface integrated within RAM Connection.
This enhancement helps users:
- Resolve workflow questions more quickly
- Access documentation more efficiently
- Discover product capabilities
- Improve productivity during connection modeling and design workflows
This integration streamlines access to technical information without requiring users to leave the application.
Close
Figure 2. Example AI-assisted workflow guidance using Bentley Copilot inside RAM Connection.
2. Bolt Database Refactoring with Fy, Fu, and Custom Grades Support.Improvements to the bolt database structure add explicit Fy and Fu mechanical properties and support for custom bolt grades.
Previously, bolt strength calculations relied primarily on predefined grade names, which could create inconsistencies when regional or custom bolt specifications were used.
The updated bolt database now:
- Uses explicit Fy and Fu properties for strength calculations
- Supports user-defined custom bolt grades
- Improves compatibility with regional bolt specifications
- Provides more accurate bolt strength calculations
Close
Figure 3. Updated bolt database including Fy, Fu, and custom grade definitions.
This enhancement increases flexibility for international projects and specialized fabrication requirements.
Close
Figure 4. Example custom bolt grade definition within the RAM Connection bolt database.
3. EN 1993 / IS 800 Chevron (CVR) and Vertical X-Brace (VXB) Connections.Support is now available for Chevron (CVR) and Vertical X-Brace (VXB) connection types for EN 1993 and IS 800 design codes.
This implementation expands the bracing connection library for European and Indian steel design workflows.
Users can now design:
- Chevron bracing connections
- Vertical X-brace connections
using EN 1993 and IS 800 code provisions directly within RAM Connection.
The implementation includes support for all connector configurations for:
- Brace-to-gusset connections
- Gusset-to-beam connections
This allows users to model and design a broad range of braced-frame connection configurations.
Close
Figure 5. Chevron (CVR) bracing connection designed using EN 1993 provisions.
It also reduces the need for manual calculations or alternative code-based workarounds.
Close
Figure 6. Vertical X-Brace (VXB) connection under IS 800 design provisions.
4. Vertical X-Brace Connections with One Continuous Member.Vertical X-brace connections now allow one bracing member to remain continuous while the intersecting member is interrupted at the gusset plate. This configuration reflects common fabrication practice for vertical bracing systems and aligns the workflow with options already available for horizontal bracing connections.
Close
Figure 7. Vertical X-brace configuration with one continuous brace member.
Previously, users were required to model both brace members as interrupted at the gusset plate location, which did not accurately reflect many fabricated field conditions. The updated workflow allows users to design vertical X-brace connections that better reflect real fabrication and erection practices.
Close
Figure 8. Example vertical X-brace connection using one continuous member through the gusset plate.
5. Mitred Knee Connections for Tapered Members (EN 1993 / IS 800).Support is now available for mitred knee connections for tapered beam and column configurations under EN 1993 and IS 800 design codes. The implementation includes support for multiple plate alignment configurations, including:
- Vertical alignment
- Horizontal alignment
- Diagonal alignment
- Perpendicular alignment
This allows users to model a broader range of tapered knee connection details.
Close
Figure 9. Mitred knee connection for tapered members designed using EN 1993 provisions.
Users can now model and design mitred knee connections directly within RAM Connection without relying on manual approximations or alternative connection configurations.
Close
Figure 10. Example tapered portal frame knee connection under IS 800 provisions.
6. Base Plate Anchorage Update to ACI 318-25 and Shear Lug Enhancements.The base plate anchorage design module has been updated to ACI 318-25 provisions.
The updated implementation expands support for the following:
- Latest ACI 318 anchorage requirements
- Cross-type shear lug configurations
- Shear studs using rectangular and circular HSS sections
Close
Figure 11. Base plate anchorage design using ACI 318-25 provisions.
This enhancement improves compliance with the latest concrete anchorage requirements while expanding support for shear transfer configurations in base plate connections.
Close
Figure 12. Example shear lug configuration supported in RAM Connection 2026.
7. Enhanced Connection Elements Summary for Bill of Materials.The Connection Elements Summary report has been enhanced to include non-rectangular plates in the bill of materials output. Previously, the summary primarily reported rectangular plates, while other plate geometries such as gusset plates and circular plates were not fully included in the connection material summary.
The updated report now includes:
- Gusset plates
- Circular plates
This enhancement improves the completeness and accuracy of material summaries used for:
- Bill of materials generation
- Fabrication review
Close
Figure 13. Enhanced Connection Elements Summary including gusset plates and circular plates in the bill of materials report.
Resolved Issues:
AISC 360- Shear plate Znet calculation for unequal edge distance configurations: A new equation was implemented to calculate the plastic net section modulus Znet of shear plates for cases where the edge distance Lev differs from (s/2), making AISC Manual Equations 15-4 and 15-5 not directly applicable. The implementation follows the methodology presented in the AISC Design Examples Manual v15 for single-plate shear connections, improving accuracy for nonstandard edge distance configurations.
AISC 341- Reinforcement area not included for bolted HSS brace rupture checks: The reinforcement area for HSS braces bolted to gusset plates is now properly included in the seismic branch tensile rupture calculations, increasing the effective net area used for brace strength evaluation and updating the brace and gusset report sections accordingly.
AISC 360- Gusset beam stub splice connection using incorrect member properties: The stub-to-support design logic for gusset connections with beam stub and splice configurations was corrected to use the geometric and section properties of the actual stub member instead of incorrectly referencing the beam properties, improving the consistency and accuracy of the generated connection design results.
AISC 360- Incorrect Qf stress evaluation for rotated tubular chord sections: The stress evaluation for plastification reduction factor (Q_f) calculations was corrected for rotated chord sections in tubular truss connections by properly transferring the in-plane moment component into the design calculations, ensuring that chord face stresses and plastification checks are evaluated using the correct stress state.
AISC 360- Incorrect K-joint classification in tubular truss connections: A correction was implemented in the tubular joint classification logic for K-connections where a parameter related to branch verticality evaluation in two-branch joint configurations was producing incorrect classification results in some cases. The revised implementation now provides the correct joint classification behavior.
AS 4100- Anchor bolt section modulus and ultimate strength corrections: The AS 4100 anchor bolt implementation was corrected by updating the section modulus formulation and replacing the incorrect use of Fy with Fu where applicable in the bolt shear strength calculations, aligning the Australian code behavior with specification intent and maintaining consistency with equivalent implementations in other international design codes such as EN.
RAM Connectionis the ideal solution when structural engineers or designers need to check a specific connection, design a single connection for multiple joints, or optimize each connection in a structure. Analyze, design, and verify structural steel connections, all with comprehensive calculations, including seismic compliance. RAM Connection can check or design connections in seconds. Whether you design connections or need to check connections designed by the shop, RAM Connection is the software for you. In just one low-cost package, you get for steel frame connections the AISC ASD and LRFD, AS 4100-1998, BS5950-1, CSA S16-14, EN1993-EC3, GB50017 and IS800 connection design and optimization for shear and moment connections, braced frame connections, splices, and horizontal bracing connections. For truss connections you get the tubular connections design according to the AISC and the HSS Connection Design Manual. Through its seamless integration with the RAM Structural System, RAM Elements, and STAAD.Pro, RAM Connection raises the bar to a new level of productivity. All data regarding member sizes, joint geometry, and forces are transferred directly from either the RAM Structural System, RAM Elements, or STAAD.Pro to RAM Connection.
Designing Through Plate (TP) Connections in RAM Connection
In this video, you will learn how to design through plate shear connections for beam-column joints.
Bentley Systems, Inc.is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.
Сopyright holder \ Distributor:Bentley Systems, Inc.
Product Name:RAM Connection
Version:2026 (26.00.00.272)
Supported Architectures:x64
Website Home Page :www.bentley.com
Languages Supported:multilanguage
System Requirements:Windows *
Size in archive:456.4 mb
