Hexagon MSC CAEfatique 2025.2 Win x64 English
Free Download Hexagon MSC CAEfatique 2025.2 | 4.4 Gb
Hexagon is proud to announce the release of CAEfatique 2025.2 is a random response and vibration fatigue solver for the frequency domain plus a fatigue solver for the time domain.
Summary CAEfatique 2025.2 Release Highlights
Major updates and enhancements in CAEfatigue 2025.2 are
Fatigue Damage Spectra (FDS)
- Calculation of FDS from single and summed events
- Derivation of equivalent Power Spectral Densities (PSDs)
Frequency domain Envelopes
- Envelope visualization across all frequency-domain solvers
- Statistical analysis of envelopes
- Generation of damage-adjusted envelopes based on damage potential
Robust Design enhancements
- New correlation convergence Descriptions as sample sizes increase
- Specialized fringe Description and parameter export filters driven by decision map
Random response fatigue analysis
- New workflow to support fatigue calculations directly from Nastran H5 random response data
- Enables Diffuse Sound Field vibro-acoustic fatigue analysis using Actran workflow manager
Fatigue Damage Spectra (FDS) in CAEfatigue
Description:
This release introduces Fatigue Damage Spectra (FDS) analysis utilizing the Henderson & Piersol* formulation for generating surrogate loads from time histories and PSDs. Calculates damage spectra for single events and derives equivalent Power Spectral Densities (PSD) via Inverse FDS. A new "SN from m and c" material model support simple SN description, along with access to the full material database.
Benefits:
- Ease of use: visualization of channel and overall envelopes
- Simplification: damage equivalent load across multiple events
- Insight: consistent comparison across multiple events
Who needs it:
- Durability/fatigue CAE engineers performing frequency domain life estimations
- Test engineers processing equivalent/simplified shaker loads
Close
Fatigue Damage Related Descriptor for Random Vibration Test Environments, by G.R. Handerson and A.G. Piersol
New Frequency domain envelopes in CAEfatigue
Description:
New envelope analysis capabilities have been implemented to enhance result visualization across all frequency-domain solvers. Enables the display and statistical analysis of envelopes when connected to FFT, PSDM, or Load Scheduler inputs. Generation of damage-adjusted envelopes, allowing for the normalization of signal envelopes based on calculated damage potential.
Benefits:
- Ease of use: visualization of channel and overall envelopes
- Simplification: damage equivalent load across multiple events
- Insight: consistent comparison across multiple channels/events
Who needs it:
- Durability/fatigue CAE engineers performing frequency domain life estimation
- Test engineers processing equivalent/simplified shaker loads
Close
Improved visualization and parameter filtering in Robust Design
Description:
This release significantly advances the Robust Design analysis capabilities with new visualization, parameter filtering and debugging tools. A new "Convergence Description" in the Ant-Hill view allows engineers to track Spearman and Pearson correlation quantities as sample sizes increase. The Decision Map now drives a specialized fringe Description for visualizing element-based correlations, and export-to-csv functionality has been integrated directly into the map to respect active filters.
Benefits:
- Ease of use: correlation visualization as model fringe Descriptions
- Efficiency: deeper insight into statistical convergence
- Collaborative: easy filtering and exporting of metamodel parameters
Who needs it:
- Structural CAE engineers performing stochastic function studies and uncertainty quantification
Close
Random Response Fatigue Analysis in CAEfatigue
Description:
A new workflow has been implemented to support fatigue calculations directly from random response data (Nastran H5). This capability, driven by the new psdresp load type , allows frequency-domain fatigue analysis using response PSDs generated by external solvers like Actran or Nastran, without the need for transfer functions. The implementation includes a dedicated "Random Response" load scheduler event, control file generation, and support for both single and multi-event scenarios.
Benefits:
- Ease of use: direct result access with dedicated Random-Response option
- Speed and efficiency: no need to store/read transfer functions or calculate PSDs
- Collaborative: allows for vibroacoustic DFS and fatigue combining Actran and Nastran
Who needs it:
- Structural and vibroacoustic CAE engineers performing durability assessment under random vibration excitation typical of Aerospace and Defence.
Close
Product improvements and enhancements
Relevant product improvement in CAEfatigue 2025.2
Weld Analysis Enhancements
- Thickness correction support for frequency-domain workflows. H5 result format now support thickness correction, ensuring accurate stress scaling for shell elements in weld fatigue calculations.
- Abaqus ODB reader features intelligent cache management and enhanced spot weld parsing for complex coupling definitions.
Worst Layer
- The Fringe Descriptionter now includes a "Worst" layer option. This feature calculates the maximum (or minimum, for inverse metrics like FOS) value for each element across all layers. Specifically helpful for composite layered output (frequency domain only).
Table Import/Export Enhancements
- Directly import data into tables from a variety of file formats, including Control Files (CF), CSV, and Time History files (RSP, DAC, TXT, PCH). Additionally, table data can be exported to CSV.
Aero Load Spectrum Scalability
- The Aero Load Spectrum capability has been optimized to handle a significantly larger number of load cases.
- A new, simplified data entry method has been introduced, streamlining the configuration process for complex aero-structural models while maintaining full backward compatibility.
Performance and output
- This release includes many performance enhancements including faster DETLOAD, significantly faster
LMTRANS with H5.
- The solver now produces a combined H3D file by default removing the additional step of running an external utility.
Documentation updates
- A comprehensive review and update of the User Guide examples has been completed. Examples have been verified and aligned with the current software version, ensuring that users have access to accurate, up-to-date resources for learning and troubleshooting.
Defect fixes
- A comprehensive list is available with the release notes.
CAEfatiqueis a random response and vibration fatigue solver for the frequency domain plus a fatigue solver for the time domain. It works with mixed random and deterministic loadings or standard time domain-based loadings to provide fatigue life and damage predictions, as well as several forms of response statistics. It is exceptionally fast, easy-to-use and capable of handling very large models. The software also offers tools for loads management including digital signal processing, as well as a Robust Design feature that allow users to analyze the robustness of their FEA models to variations in FEA solution parameters. Along with these fatigue tools the CAEFatigue software includes state-of-the-art methods for loads conditioning (Fourier transforms), test design and correlation.
CAEfatigue Multiple Input PSD Random Analysis
Hexagonis a global leader in sensor, software and autonomous solutions. We are putting data to work to boost efficiency, productivity, and quality across industrial, manufacturing, infrastructure, safety, and mobility applications. Our technologies are shaping urban and production ecosystems to become increasingly connected and autonomous - ensuring a scalable, sustainable future.MSC Software, part of Hexagon's Manufacturing Intelligence division, is one of the ten original software companies and a global leader in helping product manufacturers to advance their engineering methods with simulation software and services.
Owner:Hexagon AB
Product Name:MSC CAEfatique
Version:2025.2 with resource pack
Supported Architectures:x64
Website Home Page :
https://hexagon.com/
Languages Supported:english
System Requirements:Windows *
Size:4.4 Gb
